High Leverage Multi-purpose Electrical Installation Pliers
• Effort saving eccentric lever design
• High leverage saving 30% strength than normal pliers
• Materials: 60 CRV Drop Forged Steel
• Hardness of cutting edge: 62±2 HRC
• Surface: Blackening + Machine Grinding
• Handle: TPR
• Package: Double Blister Card + Color Box + Mater Carton
←Slide to check the full table→
| SERIES | ITEM NO. | SPEC INCH |
CUTTING & STRIPPING & CLAMPING ABILITY | DETAIL PACKAGE / CTN | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| copper wire cutting Φ(mm) |
iron wire cutting Φ(mm) |
steel wire rope cutting Φ(mm)/Inch |
piano wire cutting Φ(mm) |
Bolt Shearing Φ(mm) |
Wire stripping (mm²) |
Clamping Scope (mm²) |
QTY/BOX (PCS) |
QTY/CTN (PCS) |
G.W./CTN (KGS) |
VOL/CTN (CBMS) |
MEAS/CTN (MM) |
|||
| 801 SERIES |
801085 | 8.5″ | ≤5.0 | ≤3.3 | ≤2.8 | ≤2.3 | Φ3/Φ4 | 4.0/2.5/1.5 | 0.75~4 | 12 | 72 | 29.5 | 0.053 | 555*305*310 |
• Gripping zones for flat and round material for a variety of uses,and grabs and twists wires.
• Oval jaw: for clamping screw nuts,pipe and other round workpieces
• Strips: 4.0 / 2.5 / 1.5 mm² standed wire
• Cutting steel wire,copper wire,plastic and so on. Special lasering heat treatment for cutting edge to ensure more shapper and longer working life
• Effort saving eccentric lever design
30% less effort than ordinary pliers with high-leverage design.
• Bolt Shearing
Diameter of holes : φ3 mm, φ4mm
• Clamping wire, gap: ≤1.5mm,easy for wire pulling & clamping
Clamping Scope: 0.75~4mm²
• TPR handle with ergonomic handle design,non-sliping,firm contact to the hand and fatigue reducing operation
